PV1-F
Grand Cable
Availability: | |
---|---|
Application
DC Cable PV1-F acc. to EN 50618, are intended for use in Photovoltaic Power Supply Systems at nominal voltage rate up to 1,5/1,5kV DC.They are suitable for applications indoor and/or outdoor, in industrial and agriculture fields, in/at equipment with protective insulation (Protecting Class II), in explosion hazard areas.They may be installed fixed, freely suspended or free movable, in cable trays,conduits, on and in walls.DC Cable PV1-F are suitable for direct burial where the corresponding guidelines for direct burial shall be considered.
Cable Construction
Conductor: Electrolytic tinned copper, finely stranded class 5 in accordance with IEC 60228
Insulation: Halogen-free cross-linked compound
Sheath: Halogen-free cross-linked, flame retardant compound
Insulation & Sheath Color: Red or Black
Dimension characteristics
Rated Voltage | D.C. 1.5/1.5 kV A.C. 1.0/1.0 kV |
Max. permissible operating voltage AC | 1.2/1.2 kV |
Max. permissible operating voltage DC | 1.8/1.8 kV |
Nominal Cross Sectional | 6mm² |
Number of wires in conductor | 83 |
Diameter of wires in conductor | 0.30mm |
Tolerance of wires in conductor | ±0.005 mm |
Mean Thickness of Insulation | 0.70 mm |
Mean Thickness of Sheath | 0.80 mm |
Max. Mean Overall Diameter | 7.40 mm |
Approx. Cable Weight | 92 kg/km |
Conductor D.C resistance at 20°C | 3.39 Ω/km |
